NXP’s Personal Device Manager (PDM) solution is a secure, optimized and highly-integrated platform designed to control personal insulin pumps.
The system architecture features a multiprotocol microcontroller unit (MCU) with Bluetooth Low Energy (LE) 5.4, Wi-Fi 6, a security subsystem and an LCD controller. To ensure continuous device operation, and simplify printed circuit board (PCB) design and bill of materials (BOM) it includes a power management integrated circuit (PMIC) with battery charging and gauging. To enhance connectivity, an near-field communication (NFC) reader is included for easy pairing with NFC-enabled pumps. However, a secure element is recommended to protect sensitive data and for compliance with stringent security standards.
NXP supports product longevity by meeting healthcare requirements and aligning with diverse regional supply chain needs while collaborating with original design manufacturers (ODMs) ready to bring the product to market.
For the best experience interacting with diagrams, please use a larger screen or maximize your browser window.
Select a block diagram:
Reference Design
FRDM-RW612 is a compact and scalable development board for rapid prototyping of the RW61x family of wireless MCU using the MCUXpresso Developer Experience.
Reference Design
PCA9420 is designed to evaluate NXP PCA9420UK/PCA9420BS which is a highly-integrated Power Management IC (PMIC), targeted to provide a full power management solution for low power microcontroller applications or other similar applications.
Reference Design
The OM-SE051ARD is the flexible and easy-to-use development kit for the EdgeLock SE051 IoT Secure Element product family.
Reference Design
PNEV5190MB NFC-Module is a rapid prototyping board using the PN5190B1EV front end IC for low-risk integration of high end NFC technology.
Quick reference to our software types.
1 software file
Note: For better experience, software downloads are recommended on desktop.
