NXP's insulin injector pen solutions enhance patient safety, usability and enable intelligent device functionality. They combine secure connectivity, energy efficiency and advanced sensor integration, offering a wide range of capabilities, from passive Near Field Coomunication (NFC) data logging to advanced Bluetooth® Low Energy BLE/NFC for cartridge authentication and wireless charging.
Core components include NXP's MCX microcontroller units (MCUs), power management systems (PMICs) with integrated battery charging and gauge, and secure NFC, enabling secure authentication. Additional capabilities include cartridge sensing for temperature, moisture, and pressure, as well as security features certified to Common Criteria. NXP's magnetic switches enable precise detection of needle and cartridge status.
By leveraging NXP's comprehensive portfolio, manufacturers can build differentiated, connected and secure insulin delivery devices that meet the evolving demands of modern healthcare.
For the best experience interacting with diagrams, please use a larger screen or maximize your browser window.
Select a block diagram:
Reference Design
FRDM-MCXC444 is a compact and scalable development board for rapid prototyping of MCX C444 MCUs using the MCUXpresso Developer Experience.
Reference Design
PCA9420 is designed to evaluate NXP PCA9420UK/PCA9420BS which is a highly-integrated Power Management IC (PMIC), targeted to provide a full power management solution for low power microcontroller applications or other similar applications.
Reference Design
The NTAG 5 development kit offers development PCB boards and demo kits for the NTAG family products, which is mainly used for NFC enabled IoT use cases.
Reference Design
The NHS52S04EVK board is a highly configurable, low-power and cost-effective evaluation and development board for the NHS52S04 product family.
