NXP’s hearing aid solution is built on a ultra-low power radio, NXH2004, which is Bluetooth® 5.3 LE Audio certified and supports Auracast™, MFi (made for iPhone/iPad/iPod) and ASHA (Audio Streaming for Hearing Aids), and HAP (Hearing Access Profile). It features an integrated audio DSP, enabling hearing aid algorithms to run directly on the device. NXH2004 offers extended battery life, can operate directly on Zn-Air batteries, and – when combined with NXP’s PMIC 9420 – provides a compact, power-efficient and cost-effective solution ideal for Li-ion-based hearing aids.
For the best experience interacting with diagrams, please use a larger screen or maximize your browser window.
Select a block diagram:
Reference Design
Bluetooth 5.3 LE Audio certified NXH2004 evaluation kit and enables Auracast™ with ultra-low power, ultra-low latency.
Reference Design
PCA9420 is designed to evaluate NXP PCA9420UK/PCA9420BS which is a highly-integrated Power Management IC (PMIC), targeted to provide a full power management solution for low power microcontroller applications or other similar applications.
