An Electric Vehicle (EV) charging station supplies power for recharging electric vehicles. Typical EV charging stations are made up of at least one smart controller board and one power socket board. The smart controller manages security, services and connectivity to a remote server and the power socket board distributes and measures energy.
EV charging stations require high levels of efficiency, accuracy, connectivity and security. NXP solutions meet the requirements with accurate power measurement, device management and data security. Our rich enablement supports faster time to market with less complexity and reduced cost, and NXP's product longevity program supports longer product lifecycles.
For the best experience interacting with diagrams, please use a larger screen or maximize your browser window.
Select a block diagram:
Reference Design
Development platform to quickly setup and manage secure connection from simulated EV Charging Station (EVSE) to Microsoft Azure IoT Central EV Application.
Reference Design
EasyEVSE development platform: i.MX 93 applications processor, LPC55 MCU, Wi-Fi 6, ISO 15118 communication, metrology, NFC, SE050 for secure authentication..
Reference Design
Development platform to quickly setup and manage secure connection from simulated EV Charging Station (EVSE) to Microsoft Azure IoT Central EV Application.
